GC1325L CO2 Laser Cutting and Engraving Machine

  • Model: GC1325L
  • Laser tube power: 100W 130W 150W
  • Laser tube brand: Beijing Reci EFR
  • Control system: Ruida controller
  • Product description: laser cutting machine, nonmetal laser cutting machine, 100W/130W/150W/ 180W Beijing Reci / EFR laser cutting machine
  • INQUIRY   EMAIL

GC1325L CO2 Laser Cutting and Engraving Machine

Working Area
1300x2500mm / 1500x3000mm
Transmission
Stepper motor, square guide rails, belt transmission
Laser Power
60w/80w/100w/150w/180w
Laser Type
Sealed Co2 Laser Tube
Cooling Type
Water Cooling
Laser Output Control
0-100% Set by Software
Smallest Character Engraving
Chinese: 2.0mm*2.0mm, English 1.0mm*1.0mm
Positioning Accuracy
0.05mm / 0.02mm
Max. Cutting Speed
40000mm/min
Max. Engraving Speed
70000mm/min
Controlling Software
Ruida controller
Graphic Format Supported
DST PLT BMP DXF DWG AI LAS, etc
Compatible Software
CORELDRAW, PHOTOSHOP, AUTOCAD, etc
Power Supply
AC110V/220V, 50HZ/60HZ

Parameter of CO2 Laser Nonmetal Cutting Machine GC1325L :

  • Main configurations:

    #Working size 2500*1300mm

    #Reci EFR 100W 130W 150W laser tube

    #RD control system,USB offline

    #Taiwan PMI guide rail

    #Blade table

    #High quality belt transmission

    #USA lens and mirrors

    #Heavy duty body

    #Water protection switch

    #Industrial wather chiller CW3000 CW5000 CW5200


Thicken Machine Bed

Adopt Thicken machine bed, heavy loading,
Not easy to get distort
Adopt Advanced Germany Mix Cutting Technology
It supports can cut acrylic, wood, MDF engraving and cutting.

High precision linear guide rail

Dust-proof and auto lubricate with lower noise volume
High accuracy and long life span


Power Supply

Model: 80W/100W/130W/150W
Original: China
Warranty period: 1 Year
Normal service life: 3 Years

Controller(Mainboard)

Model: AWC708C
Original: China
Cutting speed: 0-36000mm/min
Engraving speed: 0-64000mm/min
Resetting: 0.01mm
Positioning accuracy: 0.025mm
Highest scanning precision: 2500DPI
Graphic format: AI ,CDR BMP,JPG,DST,PLT,DXF,DWG,TIFF,PSD
Supported software: CoreDraw, photoshop, Autocad, etc.
Smallest cutting characters: Chinese 2x2mm . English 1x1mm
Input Power: 220V/ 110V / 60HZ
Whole Power: <1100w
Operating temperature: 0-45°C
Operating humidity: 5-95% Free of condensed water


Water cooled chiller

RECI laser tube W6 model:


Unique Mirrors and Lens Cooling Technology

All mirrors and lens is cooled by water
Takes the mirror heat during working
USA "II-IV" Brand Imported Mirrors & Lens
Equipped with luxury consumables
Imported reflect mirror and focus lens,
Makes high efficiency and steady.


Control Panel

Ruida
Original: China
Input format: AI ,CDR BMP,JPG,DST,PLT,DXF,DWG,TIFF,PSD
Supported software: CoreDraw, photoshop, Autocad, etc.


Standard Parts

  • Red Light pointer
  • 1× CW-3000/5000/5200 Water Chiller/Water Pump
  • 1× Honeycomb table/Blade Table
  • 1× Air compressor + 1×Exhaust blower + 1×Smoke pipe.
  • 1× USB cable (Connecting pc and machine)
  • 1× CD (Including PHCAD operating software, user-friendly instruction manual, guiding videos.)
  • 1× Power cable
  • 1× Tool box
