Laser Marking Machine

Portable Coding Dot Peen Marking Machine For Metal Nameplate

Portable Coding Dot Peen Marking Machine For Metal Nameplate

Marking area : 150X90mm
Marking Depth: 0.01~2mm
Marking Type: Handheld Portable Pneumatic Marking
Process material: steel plate metal nameplate aluminum
Product description: Portable Metal Dot Pin Marker machine dot peen machine for metal
INQUIRY EMAIL

pneumatic marking machine :

This pneumatic marking machine enables flat surface marking as well as circumference marking of the work piece. Mark figures and Chinese/English characters on work piece of various materials, including the fields of automobile, motorcycle, mechanism, petroleum, aeronautical and space, electric apparatus and suitable for markings on steel, metal, nonmetal and hard plastic materials.

It is portable type which is special for marking on large-sized and unmovable metal items and some hard nonmetallic work pieces. It can also work with pipelining.

Due to its small size and portable type, this model is widely used for marking characters, serials numbers and VIN codes on automobile or bodywork of car frames, automotive chassis, connecting rods, petrol pipe, crossbeam, mechanical parts, machine tools, metal pipes, pump bodies, fastening pieces and various hard plastic products.

Portable Metal Dot Pin Marker integrates computer, automatic control and precise machinery. It is industrial marking equipment which can make logo (characters, letters, VIN code, serial numbers, date and graphics) on metal or no-metal work pieces permanently.

Standard Marking Area	150mm×100mm
Optional Working Area	200mm×100mm / 300mm×200mm / 400mm×300mm
Marking Speed	≤50mm/second (for characters height of 3mm or 3-4 numbers /second)
Marking Depth	0.1~2mm
Lifting Range	0-300 mm
Maximum Fixture Diameter	0-100mm, 0-200mm
Repeated Accuracy	0.01 mm
Pin Hardness	HRC 73
Power Supply	220V±10%, 50Hz
Machine Power	≤400 W
Working Environment	-5~40 °C
Weight	65 Kg

Application of pneumatic marking machine :

1. Motor industry: printing manufacture serial number, manufacture date, name, brand, etc. on the body, frameworks, base plate, pillar, engine, connecting rod, cylinder, piston, cylinder sleeve, etc.

2. Mechanical industry: marking on mechanical parts, machine tools, hardware products, steel tubes, sleeves, collars, rollers, pump valves, ring flanges, fasteners

3. Marking on apparatus, electromechanical instruments

4. Marking on hard plastic products,

5. Print numbers and manufacture serial numbers, etc. on aluminum, copper and stainless steel labels(nameplate)

6. Marking dial plates
